Rayners BOFA DustPRO 50

The BOFA DustPRO 50 industrial particle and dust extractor has been developed to help with the filtration of swarf and small particulates during processes such as routing, mechanical engraving, grinding and turning.

The pump used in the DustPRO 50 is brushless and designed for continuous running for long periods of time before servicing.

Rayners Bofa Extractor

Rayners BOFA DustPRO 50


  • Effective filtration of particulate, dust & swarf generated during processes.
  • Reliable systems you can have confidence using.
  • Brushless motors for long running life.
  • Adaptable range for different applications and sizes of particles.
Get Finance

Ensure risks to health and safety are minimised with trusted extraction systems and machinery.

Perfect solutions for rotary engraving, mechanical engraving, grinding, CNC and more

BOFA image 800 x 780


Dimensions (LxWxH)295 x 320 x 575 mm
Voltage230 V - 1 ph.
Power Consumption0.4 kW - 50/60 Hz Max.
Negative Pressure100 mbar Brushless Motor
Max. Airflow80 m3/h
Cabinet ConstructionPowder Coated Mild Steel
Weight23 kg
Bag Filter Capacity6.4 litres
Bag Filter Efficiency95% @ 0.9 microns
Sound Level<64 dBA
(at typical operating
