Roland SF-200 Eco Solvent Flatbed Printer

Roland’s ECO Solvent printer provides the same speed and quality of print as the LEF UV printers, but this machine is also ideal for those more sensitive applications. These include products which are actively used by kids and frequent skin contact toys, soothers, food containers (lunch-boxes, drinking bottles etc.). It is also ideal for printing production of sports apparel, heath and personal hygiene items, glasses frames, medical devices, promotional items, safety eqiupment, cosmetic containers. The list goes on.

The Print Pro Base

This solution is also complimented by an optional active charcoal filter with heated full-size drawers, which allows the solution to be used in retail environments and ensures faster drying time and de-gassing of the final product.

IDEAL FOR PRINTING MORE SENSITIVE APPLICATIONS

Roland SF-200 Eco Solvent Flatbed Printer

£19,999
+ VAT

Features

  • Print Pro Base: £3499 + VAT
    (click here for details)
  • Print Table Size: 508 x 330mm
  • Maximum Material Thickness: 100mm
  • Materials: ABS, PVC, TPU, PET, PP, PPMA, Wood
  • En 71-3 Tested. (For toy safety)
  • Extend your product offer and widen your market place with the new SF-200.
Get Finance

Applications

eco solvent print example

Food containers

eco solvent print example

Personal Items

eco solvent print example

Plastic
Toys

eco solvent print example

Wood Utensils

eco solvent print example

PVC &
Plastics

eco solvent print example

Bodycare Products

Specifications

ModelSF-200
Printing methodPiezo ink-jet method
MediaWidthMax. 538 mm (21.2 in.)
LengthMax. 360 mm (14.2 in.)
ThicknessMax. 100 mm (3.94 in.)
WeightMax. 5 kg (11 lb.)
Printing width / lengthMax. 508 (w) × 330 (l) mm (20 × 13 in.)
Printing resolutionMax. 1440 dpi
InkTypeInk specified by Roland DG Corporation
ColourFive colours (Cyan, Magenta, Yellow, Black and White)
Distance accuracy *1±0.3% of distance travelled or ±0.3 mm (±11.8 mil), whichever is greater
ConnectivityEthernet (10BASE-T/100BASE-TX, automatic switching
Power-saving functionAutomatic sleep feature
Power requirementsAC100 to 240 V ± 10%, 1.1 A, 50/60 Hz
Power consumptionDuring operationApprox. 81 W
Sleep modeApprox. 13 W
Acoustic noise levelDuring operation60 dB (A) or less
During standby49 dB (A) or less
Other dimensions1202 (W) × 962 (D) × 549 (H) mm (47.3 × 37.9 × 21.6 in.)
Weight110 kg (242.5 lb.)
EnvironmentDuring operationTemperature: 20 to 32°C (68 to 90°F) (22°C (72°F) or higher recommended), Humidity: 35 to 80% RH (no condensation)
Not operatingTemperature: 5 to 40°C (41 to 104°F), Humidity: 20 to 80% RH (no condensation)
Included itemsVersaWorks 6 RIP software, power cable, cleaning liquid, drain bottle, manuals, etc.
