Roland VersaSTUDIO BD-8 Printer
The BD-8 is a desktop UV printer capable of high-definition direct printing on a variety of shapes and materials. It supports items up to A5 size and 102mm in height. The device can also print on cylindrical objects such as bottles and lipstick casings using the optional rotary axis. It is ideal for personalising objects at an affordable price, and for environments with limited space.
Key benefits:
- Quick and easy for anyone — even those with no prior experience — to print vibrant and detailed graphics on a wide range of objects
- FlexiDESIGNER VersaSTUDIO Edition Software and VersaWorks 6 Software
- Ink configuration: EUV5 CMYKWh + Primer (220ml)
- Built-in Fume Extractor and optional New Rotary Axis (up to 17cm length)
- Utility Software to control all functions from a PC
- Compatible with Roland DG Connect remote monitoring to reduce downtime and improve efficiency
Play Video
Roland VersaSTUDIO BD-8 Desktop Flatbed
Features
-
Add value: Perfect for multiple items like phone covers, cosmetic cases, fashion, sports memorabilia, gifts, bottles and more
-
Printable Size: Items up to A5 size and 102mm in height
-
Affordable: Ideal for personalising objects and for environments with limited space
Print and produce a wide range of signage, gifts, trophies, tool and industrial products.
Easy to set up and use.
Versatile desktop printer for use in home businesses, small offices, retail spaces and classroom settings.
Applications
Promotional Merchandise
Stationary
Packaging
Phone Cases
PVC & Plastics
Specifications
| Printing Method | Piezo ink-jet method | |
| Attachable objects to be printed on | ||
| Width | Max. 9.4 in. ( 240 mm) | |
| Length | Max. 7 in. (178 mm) | |
| Thickness | Max. 4 in. (102 mm) | |
| Weight | Max. 6.6 lb. (3 kg) | |
| Maximum printing width/printing length | Max. 8.2 in. × 5.8 in. (210 mm × 148 mm) | |
| Ink Type | ECO-UV (EUV5) 220 ml cartridge | |
| Colors | Five colors (cyan, magenta, yellow, black, and white) and primer | |
| Ink-curing unit | Built-in UV-LED lamp | |
| Printing resolution (dots per inch) | Max. 1,440 dpi | |
| Connectivity | Ethernet (100BASE-TX/1000BASE-T, automatic switching) | |
| Power-saving function | Automatic sleep feature | |
| Rated input | 100-240 Va.c. 50 / 60 Hz 1.1A | |
| Power consumption | During operation | Approx. 90 W |
| Sleep mode | Approx. 30 W | |
| Acoustic noise level | During operation | 59 dB (A) or less |
| During standby | During standby | 52 dB (A) or less |
| Dimensions (Width x Depth x Height) | 30.3 in. × 23.1 in. × 22.9 in. | (768 mm × 586 mm × 580 mm) |
| Weight | 134.5 lb. | (61 kg) |
| Environment | During operation *1 | Temperature: 68°F to 89.6 °F (20°C to 32°C) (71.6 °F [22 °C] or higher recommended) |
| Humidity: 35%RH to 80 %RH (no condensation) | ||
| Not operation | Temperature: 41°F to 104 °F (5°C to 40 °C) | |
| Humidity: 20%RH to 80 %RH (no condensation) | ||
| Included Items | Power cord, Cleaning liquid, User's Manual, Software (FlexiDESIGNER VersaSTUDIO Edition, VersaWorks, Roland DG Connect), etc. |
