Roland DE-3U Desktop Engraver

The DE-3U intuitive and intelligent engraving machine delivers impressive versatility and fast automated production.

Now with laser-pointing technology to ensure excellent precision every time without the surface burning that laser engravers produce. This is a small footprint device which performs like a production class engraver, it will fit into any office, industrial or retail environment.

The DE-3U’s safety cover and user friendly operation make this machine the ideal engraving solution for sign makers ,retailers, equipment manufacturers, awards and gift suppliers.

rayners DE 3 cover
Play Video

Roland DE-3U Desktop Engraver​

Features

  • Materials: Acrylic, PVC, ABS, Polycarbonate, Wood, Stainless Steel, Aluminium
  • Work Table Size: 305mm x 230mm
  • Maximum material thickness: 40mm (38mm when using the nose cone)
Get Finance

Engrave onto a wide range of signage, gifts, trophies, tool and industrial products.


Laser pointer for quick set up and precision


Avoid scratching with easily-applied nose cones


Ethernet connection with LAN connectivity


Included the new Dr.Engrave Plus Software

engraving printing machines

Applications

Roland DE-3

Acrylic Awards & Signs

Roland DE-3

Glass

Roland DE-3

Signage & Plaques

Roland DE-3

Metals including Gold & Silver

engraving printing machines

PVC & Plastics

Roland DE-3

Wooden Plaques & Signs

Specifications

Work table size305mm x 230mm
12.0079in x 9.05512in
Maximum Work Area (Work Envelope)12” (X) x 9.1” (Y) x 1.6” (Z)
305 mm (X) x 230 mm (Y) x 40mm (Z)
XYZ Axis Drive SystemStepper motor, 3-axis simultaneous control
Operating SpeedXY axis:0.1 ~ 60 mm/sec.
Z axis:0.1 ~ 30mm/sec.
Software Resolution0.004” (0.01 mm) /step
Mechanical ResolutionXYZ-axis:0.00125 mm/step
Spindle MotorBrushless DC Motor
Spindle Speed5,000 ~ 20,000 rpm
Tool LoadingCutter Holder, Collet Type
Maximum Material Thickness40 mm(38 mm when using the nose cone)
ConnectionUSB
Machine LanguageRML-1
Power SupplyVoltage and FrequencyAC 100V – 240V ± 10%、50/60Hz(Overvoltage category: Category Ⅱ, IEC60664-1)
Rated Current1.0 A
Power Consumption80 W
Operating NoiseWhile Operating:60 dB(or less)
Standby:40 dB(or less)
External Dimensions2'02" (W) x 1'9" (D) x 1'2" (H)
(616 mm (W) × 587 mm (D) × 390mm (H))
Machine Weight75 lbs (35 kg)
Installation EnvironmentIndoor use, altitude:2000 m or less
Temperature5 to 40 °C
Humidity35 to 80% (no dew condensation)
Environment pollution degree:2
Bundled Accessories"Power cord, power adapter, USB cable, nose cone unit (resin / metal components), nose unit set screw (fixing screw, spring), spare set screw (for cutter holder) , Solid collet (∅ 3.175 mm), spanner wrench, hex wrench, hex driver, adhesive sheet, dust collector adapter, DGSHAPE Software Package CD, Setup Guide"
